1800 Growatt Sofar Huawei Solis Sungrow Grid Tie Inverter Solar Inverter 3-200kw Rated Power
Basic Info.
| Model NO. | Huawei-inverter |
| Circuit Topologies | Half-Bridge Type |
| Rated Grid Voltage | 220V/230V/240V |
| Grid Frequency Range(Hz) | 47-52 or 57-62 |
| DC Switch Rating for Each MPPT |
Yes
|
| Output Over Voltage Protection-Varistor |
Yes
|
| Trademark |
Growatt
|
| Specification | 1, 035 x 700 x 365 mm |
| HS Code |
8504403090
|
| Power Source |
Solar Power
|
| Nature of Wave String | Sine Wave Inverter |
| Rated Grid Frequency(Hz) | 50/60 |
| DC Reverse Polarity Protection | Yes |
| Output Over Current Protection | Yes |
| Grid Monitoring |
Yes
|
| Transport Package | Carton Box with Pallets |
| Origin |
China
|
Product Description
Technical specifications
|
Model
|
SUN2000 -12KTL-M0
|
SUN2000 -15KTL-M0
|
SUN2000 -17KTL-M0
|
SUN2000 -20KTL-M0
|
|
Efficiency
|
||||
|
Max. efficiency
|
98.50%
|
98.65%
|
98.65%
|
98.65%
|
|
European weightedefficiency
|
98.00%
|
98.30%
|
98.30%
|
98.30%
|
|
Input (PV)
|
||||
|
Recommended max. PV power
|
24,000 Wp
|
29,760 Wp
|
29,760 Wp
|
29,760 Wp
|
|
Max. input voltage
|
1,080 V
|
|||
|
Operating voltage range
|
160 V ~ 950 V
|
|||
|
Start-up voltage
|
200 V
|
|||
|
Rated input voltage
|
600 V
|
|||
|
Max. input current per MPPT
|
22 A
|
|||
|
Max. short-circuit current
|
30 A
|
|||
|
Number of MPP trackers
|
2
|
|||
|
Max. number of inputs per MPPT
|
4
|
|||
|
Output
|
||||
|
Grid connection
|
Three phase
|
|||
|
Rated output power
|
12,000 W
|
15,000 W
|
17,000 W
|
20,000 W
|
|
Max. apparent power
|
13,200 VA
|
16,500 VA
|
18,700 VA
|
22,000 VA
|
|
Rated output voltage
|
220 Vac/ 380 Vac, 230 Vac/ 400 Vac, 3W + N + PE
|
|||
|
Rated AC grid frequency
|
50 Hz / 60 Hz
|
|||
|
Max. output current
|
20 A
|
25.2A
|
28.5A
|
33.5A
|
|
Adjustable power factor
|
0.8 leading ... 0.8 lagging
|
|||
|
Max. total harmonic distortion
|
≤3 %
|
|||
Technical specifications
|
Model
|
SUN2000-60KTL-M0
|
SUN2000-100KTL-M1
|
|
Efficiency
|
||
|
Max. efficiency
|
98.9% @480 V; 98.7% @380 V / 400 V
|
98.8% @480 V, 98.6% @380 V / 400 V
|
|
Europeanefficiency
|
98.7% @480 V; 98.5% @380 V / 400 V
|
98.6% @480 V, 98.4% @380 V / 400 V
|
|
Input
|
||
|
Max. Input Voltage
|
1,100 V
|
1,100 V
|
|
Max. Current per MPPT
|
22 A
|
26 A
|
|
Max. Short Circuit Current per MPPT
|
30 A
|
40 A
|
|
Start Voltage
|
200 V
|
|
|
MPPT Operating Voltage Range
|
200 V ~ 1,000 V
|
|
|
Rated Input Voltage
|
600 V @380 Vac/ 400 Vac; 720 V @480 Vac
|
720 V @480 Vac, 600 V @400 Vac, 570 V @380 Vac
|
|
Number of MPP trackers
|
6
|
10
|
|
Max. number of inputs
|
12
|
20
|
|
Output
|
||
|
Rated AC Active Power
|
60,000 W
|
100,000 W
|
|
Max. AC Apparent Power
|
66,000 VA
|
110,000VA
|
|
Max. AC Active Power (cosφ=1)
|
66,000 W
|
110,000 W
|
|
Rated Output Voltage
|
220 V / 380 V, 230 V / 400 V, default 3W + N + PE; 3W + PE optional in settings; 277 V / 480 V, 3W + PE
|
480 V/ 400 V/ 380 V, 3W+(N)+PE
|
|
Rated AC Grid Frequency
|
50 Hz / 60 Hz
|
50 Hz / 60 Hz
|
|
Rated Output Current
|
91.2 A@380 V, 86.7 A @400 V, 72.2 A @480 V
|
120.3 A @480 V, 144.4 A @400 V, 152.0 A @380 V
|
|
Max. Output Current
|
100 A@380 V, 95.3 A @400 V, 79.4 A @480 V
|
133.7 A @480 V, 160.4 A @400 V, 168.8 A @380 V
|
|
Adjustable Power Factor Range
|
0.8 leading... 0.8 lagging
|
|
|
Max. Total Harmonic Distortion
|
||
